Folding Unit TriFold 360

Folding unit TriFold 360 is designed primarily for folding of pre-creased material up to 350 gsm. It is ideal to combine the unit with Cyklos creasers GPM 450 Speed or AirSpeed 450, however it might be used also with competing creasers by other brands. TriFold 360 enables the creation of 5 fold types including the most common 1/2, C, or Z. The fold is being achieved by a combination of manually adjustable fold plates and high-diameter rubber rollers. This simple and inexpensive but revolutionary solution allowed us to create one of the most demanded product in the world of low-production digital press.

pictogram fold types TriFold 360
  • professional fold on all kinds of stock up to 350 gsm
  • 5 fold types including 3 most common (1/2, C, Z)
  • simple connection with Cyklos creaser GPM 450 Speed and AirSpeed 450
  • possible connection with creasers by other brands
  • robust but simple construction for a great price
  • precise, nicely ironed fold

Parameters

PAPER GRAMMAGE
  80 - 350 gsm
PAPER FORMAT
  SRA3, A3, A4, A5, atypical formats
SPEED
  up to 6.000 sheets/h
depends on speed of creaser
LENGTH OF FOLD PLATES
  X = 460 mm
Y = 320 mm
TRANSPORT TABLE DIMENSIONS
  l = 620 mm
w = 360 mm
DIMENSIONS
  l = 1635 mm
w = 565 mm
h = 1310 mm
WEIGHT   113 kg (nett)
148 kg (brutt)
VOLTAGE / FREQUENCY
  230 V / 50 Hz
CONTENT OF PACKING
  deflector plate for 1/2 fold
fold plate Y for higher grammage
mobile table
